CV 155 Compact

The light and super compact welding machine CV 155 is suitable for applications in car and locksmith workshops, small metal production plants and maintenance shops.

This single phase 230 Volt machine is fitted with copper primary and secondary transformer windings, cooling fan, inductor, high-power motor for the wire feeder and a EURO connector for torch connection.

Its main advantages are that it is usable on single phase power supply, its simple control, very good welding capabilities and its high reliability.


Power supply 50/60 HZ1x230 V
Welding current range30-155 A
Duty cycle 100%55A
Duty cycle 60%70A
Duty at max. L25%
Wire feeding speed1-15 m/min
Diameter of wire0,6-0,8 mm
Protection degreeIP21
Dimensions740 x 335 x 610 mm
Weight35 kg
